Product Description
In most of the electrical system, Ladder Type Cable Tray is designed to be installed as good supporting system. Basically, it supports insulated electric cables that are required for communication and distribution. Therefore, our range has become an alternative of open wiring or electrical conduct system. In most of the commercial and industrial construction, this range is ideal for promoting proper cabling system. At the time of wire changing, Ladder Type Cable Tray is specially required as the new cables can easily be placed on it without any pulling.
Key features:
- High strength
- Durable working
- Resistance to corrosion
Specifications:
- Length: 3000 mm
- Material: Steel
- Side Rail Height: 50-600 mm
Exceptional Durability and Fire ResistanceLadder Type Cable Trays are engineered to offer optimal performance in environments demanding flame resistance and long-term durability. Their galvanized or powder-coated finish protects against corrosion, extending lifespan in both indoor and outdoor settings. These features ensure reliable operation in essential infrastructure.
Flexible Mounting and Comprehensive AccessoriesDesigned for diverse installation scenarios, these trays support wall, floor, and suspended mounting. With a versatile range of accessories such as bends, tees, reducers, crosses, and covers, installers can customize the cabling path for efficient and safe electrical network layouts.
Efficient Cable Management and Heat DissipationThe open, ladder-style design promotes excellent airflow, significantly reducing the risk of overheating. This allows for direct cable inspection and easier maintenance while supporting high load capacities (up to 400 kg) with minimal deflection, making it ideal for demanding applications.
FAQs of Ladder Type Cable Tray:
Q: How does the ladder type cable tray ensure fire and corrosion resistance?
A: The cable tray offers fire resistance due to its inherent design and material selection. Corrosion protection is achieved through hot dip galvanization, pre-galvanization, or powder coating, ensuring long-lasting performance indoors and outdoors even in challenging environments.
Q: What materials and finishes are available for these cable trays?
A: Ladder type cable trays are available in mild steel, stainless steel, aluminum, and GI. Surface finishes include hot dip galvanized, pre-galvanized, painted, or powder coated options, allowing selection based on environmental exposure and project requirements.
Q: Where can these cable trays be installed, and what mounting options exist?
A: These trays are designed for use in commercial and industrial sectors and can be installed both indoors and outdoors. Mounting options include wall-mounted, floor-mounted, and suspended installations, providing flexibility to meet diverse project needs.
Q: What is the benefit of the open ladder design in these trays?
A: The open ladder design allows for efficient ventilation and heat dissipation around the cables, reducing the risk of overheating. It also facilitates easy inspection and maintenance, which is essential for reliable electrical management.
Q: How are the cable trays joined during installation?
A: Trays are connected using coupler plates and bolts, forming a secure linkage between sections. This joining method enhances structural integrity and enables the extension or redirection of cable routes as needed.
Q: Are these cable trays load tested, and what are their load-handling capabilities?
A: Yes, all trays undergo load tests as per IS standards. Depending on the dimensions, they can accommodate a maximum working load between 150 kg and 400 kg, with deflection remaining below 10 mm at peak load capacities.
Q: What range of sizes and accessories are offered for these trays?
A: Tray widths range from 150 mm to 1200 mm, side rail heights from 50 mm to 150 mm, and standard lengths are 2500 mm. Accessories such as bends, tees, reducers, crosses, and covers are available to create tailored cable management solutions for your facility.
